FEATURES AND BENEFITS:•RoHS Compliant•Easily terminate all four pairs using the Legrand Punch & Go Tool (AC3400)•RJ45 Inserts can be terminated with any 110 punchdown tool•Exceeds EIA/TIA 568A/B Cat 6 Performance Specifications•Humidity: Max Noncondensing 93%•Material: Phosphor Bronze Alloy•Mounting: Wallplate or Strap•OhmValue: Contact Resistance: Spring Wire – 20 milliohm max, IDC – 2.5 milliohm max•Operating Temperature (Celsius): -10°C to 60°C•Storage Temperature: -40°C to 70°C•Wire Gauge: 22 – 24 AWG•Receptacle Type: RJ45 Female•Number Of Receptacles: 1•Finish: 50 microinches 24K Hard Gold over 70-100 microinches Nickel•Pair Count: 4•Termination: via Punchdown Tool•Connection Type: 8P8C•Type: Keystone Insert•Input Plug Type: RJ45 Male
Recessed hex nut does not allow for jack rotation
RJ45 Inserts can be terminated with any 110 punchdown tool
Exceeds EIA/TIA 568A/B Cat 6 Performance Specifications
Available in Black, Brown, White, Light Almond, Grey, Blue, Orange
Available in contractor packs
Specifications
Brand Name
On-Q
Sub Brand
On-Q
Item Name
Keystone Connector
Type
RJ45, Female
Cable Type
Category 6
Number of Positions
8
Termination Style
A/B Quick Connect, Insulation Displacement
Color
Light Almond
Cable Size
24 – 22 AWG
Number of Contacts
8
Voltage Rating
1000 V
Contact Resistance
20 mO (Max, Spring Wire Contact)
Material
Phosphor Bronze, High Impact Flame Retardant Plastic Housing
Finish
Sn Alloy Plated, Gold and Nickel Plated Spring Wire
Insertion Loss
0.2 dB at 100 MHz
Insulation Resistance
500 MO
Plug Retention Force
50 N
Temperature Rating
14 – 140 °F
Dimensions
0.76 x 0.67 x 1.18 in
Environmental Conditions
0 – 93% RH Non-Condensing
For Use With
Round, Flat and Solid Core Cables
Standards
ANSI/TIA-568-C.2
Application
Residential use
UPC
804428036777
