Mini-Com® TX6™ PLUS UTP Jack Modules are a component of the TX6™ PLUS UTP Copper Cabling System. This end-to-end system is interoperable and backwards compatible, providing design flexibility to protect network investments well into the future. With certified performance to the ANSI/TIA-568-C.2 Category 6 and ISO 11801 Class E standards, this system is ideal for today’s high performance workstation applications. With certified performance to the ANSI/TIA-568-C.2 Category 6 and ISO 11801 Class E standards, these systems will support the following applications:• Ethernet 10BASE-T, 100BASE-T (Fast Ethernet), 1000BASE-T (Gigabit Ethernet)• 155 Mb/s ATM, 622 Mb/s ATM, 1.2 Gb/s ATM• Token Ring 4/16• Digital video and broadband/baseband analog video• Voice over Internet Protocol (VoIP)
Specifications
| Brand Name | Panduit | Sub Brand | Mini-Com |
| Item Name | Cat 6 UTP Jack Module | Type | RJ45, Unshielded, Universal |
| Cable Type | Category 6 | Number of Positions | 8 |
| Termination Style | Insulation Displacement | Color | White |
| Cable Size | 26 – 22 AWG | Number of Contacts | 8 |
| Material | ABS/Plastic | Dimensions | 0.62 in W x 1-1/2 in D x 0.71 in H |
| For Use With | Round and Solid Cables, Litz Wire Conductor | Application | Unshielded |
| UPC | 074983395538 |
