9680341, Palmgren Radial Arm – 5 Speed Bench step pulley drill press
Palmgren’s radial arm drill presses have an extended reach, tilting drill head that is ideal for large or odd-shaped work pieces.The table tilts 45° left or right allowing easy machining of holes at almost any angle.
Features:
- Durable cast iron head, table & base
- Spindle supported by high quality ball bearings
- Rack and pinion table raiser
- Table tilts 45° right & left and swivels 360° around the column
- 1/2″ through table & base slots for easy mounting and clamping of workpiece
- Front mounted safety, paddle on/off switch
- Drill chuck & key
Specifications:
| Model | 80341 |
|---|---|
| Swing | 9 to 33 in |
| Motor HP | 1/2 HP |
| Voltage | 115 |
| Amps | 4.8 A |
| Capacity Cast Iron | 5/8 in |
| Spindle Speeds | 5 |
| RPM | 575-3520 |
| Spindle Taper | MT2 |
| Spindle Travel | 3- 5/32 in |
| Spindle to Table | 15 in |
| Table Work Surface | 8-7/8 x 9 in |
| Table Slots | 1/2 in |
| Height | 37 |
| Width | 10 in |
| Depth | 33 in |
