9680451, Palmgren Pneumatic Hand Tapper, 150 rpm
Palmgren’s pneumatic hand tapper is engineered to make your tapping job easier, safer and more efficient. It is ideal for all general purpose tapping making time consuming hand tapping obsolete. It uses a pneumatic high-reversal-type motor with added torque to easily handle a broad range of tap sizes. The tapping cycle starts at the correct speed and reverses instantly. A quick change tool holder adaptor is standard. The quick change tool holder design provides the ultimate in tap changing flexibility. It allows the tool to accept a broad range of both inch and metric tap holders fast and easily. The clutch built into the tap holder ratchets when the tap bottoms, hits any interference or begins to dull. This makes tapping both blind and through holes simple and aids in the elimination of broken taps. Whether you have only a few holes or many to tap the Palmgren hand tapper can save you up to 90% of time as compared to tapping by hand.
Features:
- 1/8″ to 7/16″ capacity in mild steel
- Ergonomic comfort grip
- Adjustable side handle
- Trigger reverse
- Quick change tooling adaptor
- Precision machined and hardened gear reduction
- High torque reversible air motor
Specificaitons:
| Item No | 9680451 |
|---|---|
| Weight | 2.6 LB |
| RPM | 150 RPM |
| CFM | 27 CFM |
| HP | 0.5 HP |
| Tapping Cap MIld Steel | 1/8 to 7/16″ IN |
| Quick Change Tooling Size | 1 |
| Noise | 80 dB |
| Air Inlet | 1/4 IN-NPT |
| Min. Hose Size | 3/8 IN |
| Max Pressure | 90 PSI |
