Grey Pneumatic 8 Piece 3/4 Drive 6-Point Deep Length Impact Socket Set (SAE) 8034D
Features
Set contains 6 Point sizes 1″ to 1-1/2″.
Includes
| Item | Size | SHP | PIN | O-Ring | R1 | A | B | C | D | E |
|---|---|---|---|---|---|---|---|---|---|---|
| 3032D | 1″ | III | 3220 | 3210 | 3110 | 1.5 | 1.57 | 2.36 | .98 | 3.35 |
| 3034D | 1-1/16″ | III | 3220 | 3210 | 3110 | 1.5 | 1.57 | 2.36 | 1.06 | 3.35 |
| 3036D | 1-1/8″ | II | 3221 | 3211 | 3111 | 1.65 | 1.65 | 2.36 | 1.14 | 3.35 |
| 3040D | 1-1/4″ | III | 3221 | 3212 | 3111 | 1.73 | 1.93 | 2.36 | 1.26 | 3.35 |
| 3042D | 1-5/16″ | III | 3221 | 3212 | 3111 | 1.73 | 1.97 | 2.36 | 1.34 | 3.35 |
| 3044D | 1-3/8″ | III | 3221 | 3212 | 3111 | 1.73 | 1.97 | 2.36 | 1.38 | 3.35 |
| 3046D | 1-7/16″ | III | 3221 | 3212 | 3111 | 1.73 | 2.01 | 2.36 | 1.46 | 3.35 |
| 3048D | 1-1/2″ | III | 3221 | 3212 | 3111 | 1.73 | 2.28 | 2.76 | 1.5 | 3.74 |
“
