Greenlee ESM Series Professional Plant Digital Multimeter DM-510A

Original price was: $162.15.Current price is: $81.08.

Sale!
SKU: GRDM-510A Category:
Share
  • Greenlee
  • ESM Series Professional Plant Digital Multimeter DM-510A
  • Measures voltage; current; resistance and frequency
  • Tests continuity and diodes
  • Backlit LCD with 6;000 count display
  • Two voltage detection modes – non-contact or using a single test lead
  • BeepJack warns when test leads are incorrectly inserted in current measurement terminals
  • Automatic and manual rangeselection
  • Relative offset mode to see changes in measurements
  • Data hold
  • Use optional USB / RS-232 interface DMSC-2U for direct-to-PC logging
  • Lifetime Limited Warranty
  • Accessories included: (2)1.5V AAA batteries; bead temperature probe (DM-210A; DM-510A only; 400F/204C max); test leads; protective boot
  • True RMS for no-compromise accuracy
  • Crest capture (peak hold) plus recording of max; min; max-min and average
  • Low impedance AutoCheck mode – automatically selects AC or DC volts; resistance or continuity; Low impedance masks ghost voltage pickup
  • Measures capacitance
  • Measures temperature using a type K thermocouple
  • Amperage Measurement : 600; 6000A; 60; 600mA; 6; 8A
  • Battery : (2) 1.5 V AAA
  • Capacitance : 60; 600 nF; 6; 60; 600; 3000F
  • Display : Backlit LCD With 6;000 Count
  • Frequency Measurement : 10Hz – 50kHz Sine Wave; 5Hz – 999.9kHz Logic Level Square Wave
  • Includes : (2) 1.5V AAA Batteries; Bead Temperature Probe (DM-210A; DM-510A Only; 400F/204C max); Test leads; ProtectiveBoot
  • Measurement Category : CAT IV 300 V; CAT III 600 V; CAT II 1000 V
  • Replacement Part : TSG-3 Sure-Grip Test Leads
  • Resistance Measurement : 600O; 6; 60; 600 kO; 6; 60 MO
  • Standard : CAT IV; CAT II; C/UL US Listed; CAT III; CE Listed
  • Sub Brand : ESM
  • Temperature Rating : K Type; -58 To 1832F (-50 To 1000C)
  • Type : Professional Plant Digital
  • Voltage Measurement : 60; 600 mV; 6; 60; 600; 1000V
