Greenlee 60 Ton Single Acting Crimping Tool RK6040

Original price was: $2,612.75.Current price is: $1,634.21.

Sale!
SKU: GRRK6040 Category:
Share
  • Greenlee
  • 60 Ton Single Acting Crimping Tool RK6040
  • Ideal tool for use in substation and transmission construction
  • Accepts Burndy L dies and Alcoa 6000 Series crimping dies
  • After completing a connection; the top of the head easily swivels 90 and can be lifted from the tool to remove the connector
  • Removing the tool from the stand exposes a lifting eye for when the tool must be used above ground level
  • RK6040 requires 10;000 psi (700 bar) single-acting hydraulic power source
  • DK6040 requires 10;000 psi (700 bar) double-acting hydraulic power source
  • Equipped with 3/8 IN screw type hydraulic couplers
  • Includes steel carrying case with storage space for dies
  • Application : For Use In Substation And Transmission Construction
  • Capacity : 300 -2000 KCMIL Copper Stranded Code Cable; 250 – 2000 KCMIL Aluminum Stranded Code Cable; 1/0 AWG – 1000 KCMIL Copper Tension Sleeves; 1/0 AWG – 2300 KCMIL Aluminum Tension Sleeves; 1/0 AWG – 2156 (Bluebird) KCMIL ACSR Tension Sleeves; 4/0 AWG – 2500 KCM
  • Crimping Force : 120000.000 LB (530.000 KN) At 10000 PSI
  • Height : 17.000 IN (432.000 MM)
  • Includes : Steel Carrying Case With Storage Space For Dies
  • Oil Volume Required : 0.75 PT (312 CC)
  • Operating Pressure : 10000 PSI (700 BAR)
  • Type : Single Acting
  • Weight : 45.000 LB (20.000 KG)
  • Width : 6.000 IN (153.000 MM)
